RB Agri Engineering truck loader/unloader are used to gentle handling all types on bags during loading/unloading from the truck.

Purpose: Z type bucket elevator are used for very gentle vertical conveying of all kinds of granular product. Especially on the seed sector, they are most suitable conveyors.

USES:- COLD STORE / WARE HOUSES/ GODOWNS

Purpose: To overcome labour shortage and to reduce loading/unloading time & cost.

Gravity roller conveyor lets a product move on rollers using the force of gravity. Gravity conveyors may be used to move boxes, cartons and rigid bottoms items.

Product Description – PIR Insulated Sandwich Panels

We are leading manufacturers and suppliers of PIR (Polyisocyanurate) Insulated Sandwich Panels, designed for superior thermal insulation, fire resistance, and long-lasting performance. PIR panels are widely used in cold rooms, clean rooms, prefabricated buildings, pharma labs, industrial enclosures, and food processing units where strict temperature and hygiene control are critical.

These panels are manufactured with a rigid PIR foam core sandwiched between two facings—commonly PPGI, stainless steel, aluminum foil, or PVC lamination—using a continuous lamination process to ensure strong adhesion and uniform insulation throughout.

?? Technical Specifications:
Core Material: Rigid Polyisocyanurate (PIR) Foam

Density: 40–45 kg/m³

Thermal Conductivity: 0.020 – 0.023 W/m·K

Panel Thickness: 40mm to 200mm

Width: 1000 mm standard

Length: Custom up to 12 meters

Joint System: Tongue & Groove / Camlock

Fire Rating: Class B-s1,d0 (EN 13501-1)

Facing Options: PPGI / SS304 / PVC film / Aluminum

Compressive Strength: >150 kPa

Water Absorption: <2%

Temperature Range: -40°C to +120°C

? Features:
Superior insulation with lower energy consumption

Self-extinguishing foam with high fire resistance

Hygienic surfaces, ideal for clean rooms & food units

Lightweight yet strong for faster installation

Corrosion-resistant facings for long durability

Eco-friendly – CFC/HCFC-free, recyclable materials

Customizable in thickness, length, facing & color

?? Applications:
Cold Storage – Chillers, freezers, banana ripening rooms

Clean Rooms – Pharma, biotech, diagnostics, R&D labs

Modular Construction – Site offices, prefab cabins

Industrial Buildings – Warehouses, factory enclosures

Food Processing – Dairy, meat, seafood, vegetables

HVAC Ducting – Pre-insulated ducting systems

?? Delivery & Service:
Pan India supply with export support

On-site technical support & installation (on request)

Lead time: 7–10 working days

MOQ: 50 sqm

?? Certifications:
ISO 9001:2015 Certified

BIS Compliant

FM-approved raw material

Fire Test (EN 13501, ASTM E84)

Water Absorption (ASTM C272)

For high-performance insulation in temperature-controlled environments, our PIR Panels provide unmatched quality, performance, and value.

AeroSound Acoustic products are highly efficient closed cell foams, with multiple applications. These products have been used in various projects and comply with the most important standards required by the thermal insulation industry.

All kind of stored agricultural products are sensitive for too high CO2 levels. Too high CO2 levels can affect the quality of the product. For example during storage of industrial potatoes, high CO2 levels can affect the frying quality. In systems where a lot of outside air is used, it is not so difficult to control the CO2 level. In hot climates, or very cold climates where use of outside air is limited, a CO2 heat exchanger will be the best solution. In warm climates outside air cannot be applied directly since this will cause an increase of the product temperature. With the help of a heat-exchanger the extracted cold air from the storage room with high CO2 level is applied to pre-cool the warm outside air with low CO2 level. In this way energy savings up to 90% can be achieved.

Components
Control panel
High efficient heat exchanger
Western Europe fans used
Housing made of galvanized steel

Agricultural products like potatoes and carrots need to be stored under quite humid conditions. Especially in dry climates it is necessary to add moisture to the air. For this application Allround has developed a high-pressure pump system which is able to humidify the air with droplets which are about 5, 5 ?m (1/1000 millimetre, or micron) in diameter on average. This provides the store with the necessary humidity.

Components
High pressure pump
Triple filter unit with 25, 10 and 5 ?m filter
Set of tubes
Anti-drip nozzles
Nylon tubing coil

As the name suggests, with box storage the products are stored in large bins. The product is stacked up to about 6 boxes high. Box storage is a very flexible way to store agricultural products. It is a perfect system to separate all de different products, varieties, sizes and qualities. The standard European size for boxes is 1200 mm x 1600 mm x 1230 mm.

Direct pressure system
Direct pressure system with closed boxes is a direct system, what means that 100 % of the conditioned air is forced to pass the product. The pressure system for boxes is a relative expensive system because the use of (expensive) specially designed closed boxes and the system needs lots of space. This pressure system for closed boxes will mainly be used as a drying system for onions, garlic and flower bulbs. It is also used in areas with lot of rain during harvest.

Advantages:

Quick drying
Highly controllable product conditions
Disadvantages:

Expensive because special boxes are needed
A lot of space is needed
Direct aspiration system
The aspire system for open boxes is also a direct ventilation system. The air in the room is conditioned and then sucked through the boxes. All kinds of standard open boxes can be used for this system. It is quite a flexible system because product can be dried and conditioned in the same place with the same system.

Advantages

Drying and conditioning of the product with same system
Highly controllable product conditions
Disadvantages

Sophisticated air plenum is needed
Indirect room ventilation system
With indirect room ventilation the room air will be conditioned and through natural convection the air will pass the product. The indirect room ventilation system for open boxes is the most flexible box system. It doesn’t matter in what way the boxes are placed in the room, different sizes of boxes can be used, even for short time different products can be stored in same room. Especially for daily fluctuating demand room ventilation system is very flexible. Wet product cannot be dried effectively with a room ventilation system, so products which have to be dried after harvest should be dried in an direct system before it will be put in the room ventilation storage.

Advantages

Quite inexpensive system
Very flexible system
Disadvantages

Product cannot be dried
Harder to control the product conditions

When storing potatoes or onions in bulk, the product is placed amass up to 3,5 to 4,5 meters high depending on the products and the conditions. This system is highly effective because it is a direct ventilation system which means that 100% of the air distribution is forced through the product. This means that with the right equipment the temperature, humidity and CO? level through the complete store are controlled.
This system is used when there are high quantities of the same variety of a product are stored for the same amount of time.

Advantages

Effective drying and cooling
Equal temperature and humidity
Optimal distribution of anti-sprouting agents
Very cost-effective method of storage
Disadvantages

Not possible to separate different lots or varieties in the same room
Special machinery is needed to fill the store
Most suitable for

Large quantities of the same product and variety
Industrial products
